Capacitive Touch Monitor KOT-430P-004
KOT-0430U-CA4P(KOT-430P-004)This PCAP touch monitor comes with below main features: 1920*1080 resolution, 3000:1 contrast ratio, vandal-proof, IP65 waterproof and dust-proof with full viewing angle. The PCAP touch monitor is industrial grade, which is with high quality. Also, VGA, DVI and HDMI interfaces are provided for use, USB port for touch. In addition, with our professional R&D engineers, customized services can be offered to meet your individual needs.
-
Advantages of PCAP Touch Monitor:
1.High sensitivity and accuracy: PCAP touch monitors offer excellent touch sensitivity, allowing for precise touch input even with a light touch.
2.Multi-touch support: PCAP touch monitors can support multiple simultaneous touch inputs, enabling advanced gestures and providing a more intuitive user experience.
3.Durability: PCAP touch monitors are built with a robust, chemically-strengthened glass surface that is highly resistant to scratches, wear, and damage.
4.Optical clarity: The glass surface of a PCAP touch monitor provides excellent optical clarity, allowing for high-quality image reproduction.
5.Slim and lightweight design: PCAP touch monitors typically have a slim and lightweight profile, which makes them easy to integrate into various systems and installations.
FAQ:1. Are you a manufacturer?Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.2. What’s your MOQ for the PCAP touch monitor?Our minimum order quantity is 1pc only.3. What is your warranty period for the PCAP touch monitor?Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional). -
Complete Machine
Model No.
KOT-0430U-CA4P(P/N:KOT-430P-004)
Series
OT
Display Type
16:9 Ratio 43" TFT-LCD
Active Area
942.9*531.25 (mm)
Monitor Dimensions (W*H*D)
1004*592*64.6 (mm)
Suggested Resolution
1920x1080 @ 60Hz
Support Colors
16.7M
Brightness (Typ.)
Pure LCD Panel
380cd/m2
With Touch Monitor
320cd/m2
Response Time (Typ.)
6.5 ms
Viewing Angle(Typ.at CR＞10)）
Horizontal(left/right)
89°/89°
Vertical(up/down)
89°/89°
Contrast Ratio (Typ.)
3000:01:00
Video Input
VGA\DVI\HDMI
Frequency (H/V)
30～80KHz / 60～75Hz
Power Supply
Type: External brick
Display voltage: DC 24V±5%
Input (line) voltage: 100-240 VAC, 50-60 Hz
Environment
Operating Temp.
-10～50°C
Operating RH
20%～80%
Storage Temp.
-20～60°C
Storage RH
10%～90%
MTBF
50,000 Hours
LED Back Light Life (Typ.)
50,000 Hours
OSD Control
Buttons
AUTO,+,POWER,-,MENU
Function
Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
CCC, ETL, FCC, CE, CB, RoHS
Touch Type
43" Capacitive touch screens, antiglare and tempered type
Touch input
USB
Support System
XP,WIN7,WIN8,WIN10,Linux,Android
Regular Warranty
1 year
-
